TSR-5G 5G-TDD Sync Detection Module

28Ghz/39Ghz MU-MIMO DAS

Key Factor

  • – Supports 5G NR TDD function(SCS 30 ~ 240Khz).
  • – Perform advanced RF analysis function using FPGA and unique software algorithm.
  • – It extracts TDD synchronous signal from RF signal of 0.1Ghz to 4Ghz.
  • – Provide synchronous signals with an accuracy of less than hundred ns.
  • – It has a relatively simple (Detector + FPGA) configuration and uses DPPLL function to operate reliably in a deep fading environment like a ICS environment.
  • – Low power design and digital design without the RF block.
  • – Support Sub-6GHz/mmWave Band

TSR-D1 TD-LTE DAS Sync Detection Module

TDD(Time Division Duplex) Repeater SYSTEM

Key Factor

  • – TDD Sync recovery from <4 GHz DAS Signal
  • – Unique digital processing technology
  • – Wide Dynamic range 0.1Ghz to 4Ghz
  • – Holdover support for input jitter/Fading environment for stable TDD switch signal output
  • – Firmware Upgradeable through GUI
  • – Tiny small form factor
  • – TDD switch offset available each output
  • – DC 3.3V Single power input
  • – No local oscillator for RF section
